Automatic Running Oil Fired Hot Water Boiler 11 Bar Working Pressure Fit Greenhouse

Yong Xing Boiler Group Co.,Ltd
Contact Now

Automatic Running Oil Fired Hot Water Boiler 11 Bar Working Pressure Fit Greenhouse

  • 1
  • 2

Brand Name : YONGXING

Model Number : WNS10-1.25-YQ

Certification : ISO9001,ISO14001,A-CLASS,SGS,BV

Place of Origin : HENAN

MOQ : 1set

Price : negotiable

Payment Terms : T/T,L/C,Western Union

Supply Ability : 1000SETS/MONTH

Delivery Time : 15-30DAYS

Packaging Details : Nude packing+wooden box+steel box ,and etc.

USAGE : Food,texitile,green house ,hotel and so on

Outer Material : Stainless steel or Color steel

Name : Oil Fired Hot Water Boiler

Capacity : 5ton,3500kw

Design Fuel : Light Oil,diesel, Heavy Oil

Operation : Automatic Running

Quality : Strict Quality System

Using Life : More Than 20 Years

Working Pressure : 11bar

Safety Device : Interlock Alarm

Contact Now

Automatic Running Oil Fired Hot Water Boiler 11 Bar Working Pressure Fit Greenhouse

General introduction of Oil Fired Hot Water Boiler

1. The Oil Fired Hot Water Boiler is equipped with multiple safety protection devices, such as water shortage protection, overpressure protection, flameout protection, abnormal pressure protection, and flue overtemperature protection.

2. The Oil Fired Hot Water Boiler has an advanced automatic control system.

3. The advanced large-capacity combustion chamber and coarse smoke pipe design are adopted to ensure full combustion

4. Automatic regulation atomizes the fuel under pressure to make it burn more fully.

5. The threaded smoke pipe has good thermal scalability, reasonable airflow design, and can effectively absorb flame heat.

Advantages of The Oil Fired Hot Water Boiler running

1. The use of threaded smoke tube and waveform furnace, large strong heat transfer effect, saving fuel consumption.

2. Excellent and reliable imported burner makes the fuel burn safely.

3. Multiple interlock protection is provided to ensure safety under various working conditions.

4. Built-in steam separator ensures steam quality.

5. Imported stainless steel packaging, beautiful and elegant, no rust.

The supply code of automatic The Oil Fired Hot Water Boiler for laundry

Product name Quantity (set)
1. Boiler main part 1
2. Imported gas/oil burner 1
3. Electric control box 1
4. Valve & Gauge used on boiler main part 1
5. Feeding water Pump 2
6. Smoke chimney 1
7. Water treatment equipment 1
8. Steam distributor 1
The above is standard, other accessories needed to contact us for details

Technical parameter of Oil Fired Hot Water Boiler

Boiler model Capacity Pressure Outlet temp. Steam temp. Fuel consume. Thermal efficiency
Light oil Heavy oil
MW MPa kg/h kg/h %
WNS0.7-0.7/95/70-Y(Q) 0.7 0.7 95 70 65.5 67.3 91
WNS1.4-0.7/95/70-Y(Q) 1.4 0.7 95 70 129.6 132.2 92
WNS2.8-0.7/95/70-Y(Q) 2.8 0.7 95 70 256 261.9 93
WNS4.2-0.7/95/70-Y(Q) 4.2 0.7 95 70 380 390.6 93.2
WNS5.6-1.0/95/70-Y(Q) 5.6 1 95 70 503 517 93.5
WNS7-1.0/95/70-Y(Q) 7 1 95 70 628 643 93.5
WNS10.5-1.0/95/70-Y(Q) 10.5 1 95 70 940 965 93.5
WNS14-1.0/95/70-Y(Q) 14 1 95 70 1250 1301 93.5

Automatic Running Oil Fired Hot Water Boiler 11 Bar Working Pressure Fit Greenhouse
